FOB Port: Shanghai or Shenzhen
MOQ: 1000PCS
Supply ability:10000PCS/DAY
Payment: TT,Paypal,Westen Union before shipment
Download Info: here
|
Item |
Specifications |
|
|
Antenna |
1558~1602MHz |
|
|
Polarization |
RHCP |
|
|
Gain |
5dBic@PCB（Zenith） |
|
|
V.S.W.R |
＜1.5 |
|
|
Impedance |
50Ω |
|
|
Dimension |
33.5*33.5*6mm |
|
|
LNA |
Gain |
28±2dB |
|
Noise Figure |
≤1.5dB |
|
|
Supply Voltage |
3~5V DC |
|
|
Current Consumption |
＜20mA |
|
|
V.S.W.R |
＜2.0 |
|
|
Mechanical |
Cable |
RG17,300mm |
|
Connector |
SMA male |
|
|
Environmental |
Operating Temperature |
-40℃~+85℃ |
|
Relative Humidity |
Up to 75% |
|
|
Vibration |
10 to 55Hz with 1.5mm amplitude 2hours |
|
|
Environmentally Friendly |
ROHS Compliant |
|
