FOB Port: Guangzhou
MOQ: 500PCS
Supply Ability:5000 Pcs/Day
Payment: TT,Paypal,Western Union
Packing information: single packing,20pcs/carton
Download Info: here
|
Electrical Specifications |
|
|
Frequency Range |
3300-3800MHz |
|
Polarization |
Vertical |
|
VSWR |
≤1.5 |
|
Gain |
17dBi |
|
Horizontal beam width |
65° |
|
Vertical beam width |
7.5° |
|
Front-to-back ratio |
≥25dB |
|
Input Impedance |
50Ω |
|
Maximum input power |
100W |
|
Lightning protection |
DC Ground |
|
Mechanical Specifications |
|
|
Input connector type |
N-K |
|
Connector place |
Bottom |
|
Dimensions |
650×128×56mm |
|
Packing size |
750×230×160mm |
|
Antenna weight |
2.7kg |
|
Radome material |
UPVC |
|
Radome color |
Gray |
|
Mechanical tilt |
0～15° |
|
Operating temperature |
-40°C to +65 °C |
|
Rated Wind Velocity |
60 m/s |
|
Mounting hardware |
￠35～￠75mm |
FAQ
Q: Can I get one sample?
A: Yes, sample is available.
Q: Have GNSS antenna 100% assembles well in stock?
A: No, all GNSS antenna will be newly assembled according to your orders including the samples.
Q: What's the delivery time?
A: 3-5 working days for the sample, 10-15 working days for quantity below 5K,.
Q: Could i use my own LOGO or design on goods?
A: Yes, customized logo and design on mass production are available.
Q: What's the payment term?
A: T/T, Paypal, western union etc.
Q: May I visit your company?
A: Sure, welcome any time.
Q: How long is the warranty?
A: 1 year for antennas and half a year for assembly cables and Connectors
